Matrix 90
Elektro pogon 08.12.2008 · marko · 1088
The first electric F3A model of this size on the Slovenian sky.
Year: 2004
Podatki o modelu
| Motor | AXI 4130/16 |
|---|---|
| Akumulator | 8s1p X-Power 4500mAh |
| Krmilnik | Jeti 75-3p opto |
| Sprejemnik | Graupner C-17 |
| Servo mehanizmi | Ailerons, elevator: HS225BB Ruder: HS5245BBM Retract: C507 |
| Oddajnik | Graupner MC-22 |
| Propeler | Graupner CAM FOLDING 14x9,5 (50mm vmesnik) |
The model is at its birth aroused some interest, since the larger electric models on the Slovenian skies were still a rarity. The first 16 flights were made with the homemade motor (up to 1 kW) and 18 cells NiCd RC 1600CP and Controller Jeti Opto 40 6-16. Prop was Menz Ultra 15x10. Amps: 39
Later was AXI motor 4130/16 with and Jeti 75 controller integrated. Bateries: Li-ion Konion 3300 6s-3P and APC-E prop 16x10.
In the 2007 season, the batteries were changed to 8S LiPo. Propeller was Graupner CAM 14x9,5.
With the model has been won 3 first places in the Junior F3A slovenian competitions and also two third places in the Senior F3A competitions.
In season 2011 has been won FAI F3A -P11 competition in Croatia (Velika Gorica).
Model is still flying.
